High-Speed Steel (HSS) Jobber Drill Bit Set - 20-Piece for Metal, Wood & Plastic Drilling - Perfect for DIY, Construction & Home Repair Projects

Features

Price For Each List Number 1500 Drill Bit Dimension Type Wire Drill Bit Point Angle 130 Degrees Point Type R Cutting Direction Right Hand Drill Bit Finish TiN Flute Length 2-1/8" Overall Length 3-9/16" Drill Bit Grouping Drill Bit Drill Bit Size #20 DepthDia. Ratio 5xD Drill Bit Material High Speed Steel Coolant Through No Decimal Equivalent 0.1610

Shank Dia. 3/16" Item Jobber Length Drill Bit Depth x Dia. Ratio 5xD Application For Aluminum Casting, Cast Iron, Low Carbon Steel 1010, 1018, Medium Carbon Steel 1035, 1045, High Carbon Steel 1065, Alloy Steels 4140, 4340, Die Steels 20 HrC, Stainless Steels 17-4PH, Hardened Steels 35 HrC Standards Not Rated Flute Type Spiral Number of Flutes 2 Shank Type - Machining Straight Finish - Machining TiN

Primary Material Application Alloy Steel, Carbon Steel Primary Material Application ISO Code P Material - Machining High Speed Steel Shank Length 37.00mm Measurement System Wire Helix Angle 30 Degrees Coolant Fed Non-Coolant Through Series 1500 Sheeter Drill No Drill Bit Point Type R Thinning Point Drill Length Class Jobber Length Secondary Material Application ISO Code H, K, M, N, P

Drill Diameter Tolerance +0.000/-0.018mm Secondary Material Application Aluminum, Cast Iron, Hardened Steel, High Carbon Steel, Stainless Steel Maximum Drilling Depth 2-1/8" Country of Origin (subject to change) Japan
